An industrial furnace is a high-temperature heating apparatus utilized across multiple industries to melt, heat, or process materials for applications such as heat treatment, metal manufacturing, glass production, and chemical reactions. These industrial furnaces produce heat through fuel combustion or electrical energy and operate at temperatures frequently above 400°C, offering precise temperature control to satisfy exact industrial specifications.
Facerom is a leading producer of both standard and custom industrial heat treatment furnaces. Their product range includes pit, box, IQ, and belt-type furnaces catering to ferrous and non-ferrous industries. Beyond heat treatment equipment, Facerom also designs and manufactures a comprehensive selection of melting and holding furnaces for non-ferrous alloys. Their offerings encompass wet hearth melting, dry hearth, aluminum holding, stack melters, crucible/pot melting, and autoladle dosing systems.
As a premier OEM supplier, Facerom’s aftermarket team is factory-trained to offer parts and service support for any industrial oven or furnace, regardless of brand. Their aftermarket services encompass preventative maintenance, temperature uniformity assessments, instrument calibrations, replacement parts, installation services, and additional support.
Glass encapsulation tubular quartz furnace is specially designed for small batch production of materials such as glass and metal encapsulation process, fungible alloy micro-oxidation.
Features
1.Working temperature RT～1000℃.
2.The diameter of furnace tube is 90mm～250mm.
3. The number of temperature zones is 3～6 optional.
4. The number of furnace tube 1～4 optional.
5. Programmable temperature control instrument, intelligent logic PID algorithm, accurate control.
6. High accuracy of imported SSR for the execution element, no noise.
7. Using ceramic fiber FEC heating module, resistance wire embedded around the heating heating rate up to 10 ℃.
8. Over-temperature protection function, when the temperature exceeds the allowable setting value automatically power off.
9. Safety protection when the furnace body leakage automatic power off.
10. Fast cooling quartz cavity air cooling or circulating water cooling according to the process can be selected
11. Product export configuration alcohol lamp placement bracket
12. Quartz cap structure is easy to put material to take material
The bell-type sintering furnace is a high-temperature sintering furnace for cyclic operation, with a shear screw lifting system for the lifting of the firing table. It can be used for intermittent production sintering process of ceramic products such as zirconia, alumina and dielectric ceramics.
Features
1. maximum temperature of 1500℃ and 1650℃ (two models of temperature are available);
2. Special riveted structure is chosen for the furnace chamber fixing, no cracking and collapse of the top for long-term use.
3. Linear guide design, smooth movement without jitter, loading and unloading products is extremely convenient and safe.
4. Pre-embedded corundum mullite at the bottom of the bearing plate to enhance support, to prevent the bearing plate from sinking and sinking.
5. Multi-stage programmed temperature control, PID adjustment, to meet the sintering requirements of multiple multi-stage process curve storage
6. Over-temperature protection function, over-temperature automatic power off.
7. High precision B-type thermocouple, accurate temperature measurement
8. Heating element is U-type silicon molybdenum rod MOSI2
9. Additional option: tail gas treatment combustion cracking device
High temperature sintering of electronic pastes, such as thick film circuits, electronic component electrodes, LTCC and stainless steel heaters, and other products.
Features
1. Working temperature 200~1000℃
2. Adopt advanced FEC ceramic fiber heating module, fast temperature rise, uniform heating, uniform and stable temperature.
3. Intelligent control system from Japan, accurate temperature control.
4. Reasonable atmosphere design, complete glue discharge, clean sintering area.
5. Automatic power off in case of over-current, overload and leakage, and over-temperature alarm to avoid over-burning of products, ensuring the safety of operators and products.
6. Atmosphere: air
FXL series five-sided heating chamber sintering furnace is mainly designed for electronic components, ceramic parts, magnetic materials, powder metallurgy, metal materials, NFC, NTC, ceramic cores, ceramic heaters, advanced ceramic materials such as de-bonding, pre-fire and sintering process, kanthal electric heating wire spiral wound corundum tube five-sided heating, excellent uniformity of temperature field.
Features
1. Maximum temperature of 1100℃ and 1300℃ (two models of temperature are available);
2. furnace chamber volume from experimental to industrial production, volume 15L ~ 700L optional;
3. Intelligent programmable temperature control instrument, which can edit, store and call multiple programs;
4. Over-temperature protection function, automatic power off when the temperature exceeds the allowed setting value;
5. Safety protection, automatic power off when the furnace body leakage;
6. Open the door and power off, high security;
7. five-sided heating, excellent uniformity of temperature field, high consistency and good repeatability;
8. electric heating wire spiral tube heating, easy to replace;
9. the bottom reserved for the new air fill inlet, the top reserved for the exhaust gas discharge port;
10. Silicon carbide bearing plate, good load bearing, mechanical impact resistance;
It is mainly used in the continuous production sintering process of PTC, NTC, MLCC and other electronic components, ceramic filters, ceramic inserts, cell phone ceramic backsheets, ceramic substrates, inductor powders, and other products.
Features
1. Working temperature RT-1600℃
2. The adiabatic material adopts imported energy-saving lightweight foam brick masonry, with high strength and no slagging.
3. Unique large dome cavity structure, good stability, uniform furnace temperature and good product consistency.
4. Classic screw transmission mechanism, smooth propulsion, no crawling and jittering.
5. Fully automatic rotary operation, reliable operation with PLC control.
6. Temperature control mode is SCR automatic voltage adjustment, with soft start, soft shutdown, constant current/voltage and other functions
7. Japan imported control instrument, precise control.
The hot air circulation debinding furnace is specially designed for the debinding process of fine zirconia, alumina and dielectric ceramics. It can realize product debinding and secondary purification of exhaust gas, which can perfectly realize the debinding process.
Features
1. Working temperature RT-550℃.
2. Hot air circulation structure with uniform temperature field and adjustable wind speed.
3. Integrated design, easy to operate.
4. 6pcs K indexing thermocouple layout all-round monitoring, 1 temperature control 5 temperature measurement, temperature recorder online display, record.
5. 0.1 level precision program temperature control instrument temperature control, PID parameters self-tuning, over-temperature, under-temperature, broken couples alarm protection.
6. The furnace chamber and material tray are all made of alloy heat-resistant plate, which is resistant to high temperature and corrosion, and the internal cleanliness of the furnace chamber is high.
7. Complete protection function, degreasing and explosion-proof system, over-temperature protection function, over-temperature automatic power off.
8. The furnace door adopts double-layer convex and concave sealing structure, with reliable sealing effect and no heat leakage.
Facerom provides a variety of industrial furnaces designed for batch processing. These furnaces are built to be highly durable, safe, and easy to maintain. Available in multiple sizes, they range from compact bench-mounted units to large floor-standing models featuring heating chambers exceeding 3000 liters. They support maximum temperatures up to 1800°C.
Our industrial furnaces can be customized with a variety of options to precisely match customer requirements. Available features differ by furnace model and may include over-temperature protection, various digital controllers, multi-segment programming, and data logging capabilities. Select a product from our industrial furnace range below to explore detailed specifications.
Facerom Furnace provides an extensive selection of standard kilns, furnaces, and plants suited to a variety of applications. Thanks to their modular design, many solutions can be adapted to your specific needs without expensive modifications. If none of our standard offerings meet your requirements, we are pleased to design and manufacture customized kilns, furnaces, or complete plants tailored precisely to your specifications.
